Air Boom || Overall 750mm H
AB750 (1450)
Want to purchase this product?
Get in touch using one of the methods below
Description
Typically deployed from response vessels where a foam filled boom would be too bulky, the reduced volume of an air filled containment boom is also an asset when they have to be transported to a new location and are ideal for open water where the high buoyancy to weight ratio assists the performance in the waves. They have excellent UV resistance and chemical resistance to acids, alkalis, solvents and hydrocarbons. We can manufacture different sizes and material types (PU and Neoprene) please contact us to discuss your application.
Specifications
| Freeboard: | 300mm |
| Draft: | 414mm |
| Overall: | 750mm |
| GSM PVC | 1450 |
| Section length: | 25m |
| Buoyancy to weight: | 30:1 |
| Weight: | 3.5kg per metre |
| Packaging volume: | 0.65m³ per 25m |
| Ballast: | 12mm hot dip galvanised chain |
| Fabric: | Orange or yellow 850gsm woven polyester scrim coated with PVC |
| Breaking Strength: | ASTM D 5035 (lengthwise & width wise 300kgf/5cm) |
| Operational temperature: | 0°C to +80°C |
Note:
Freeboard = vertical height of the product above the water
Draft = depth of the product below the water
